Cross Country® 300 (Kubota®)

Locations: In Stock Call for Availability

Item Code: LNCK4166-1

Category Engine Drive Welding Systems

Description

When you're in the cross-country pipeline welding business, your results are only as good as the arc quality, reliability, and portability of your equipment. The Cross Country® 300 engine-driven welder gives you all three of these and more. The Cross Country 300 keeps the operation simple with intuitive constant current (CC), constant voltage (CV), and TIG mode control. This enables the user to easily change over from stick to wire to TIG welding processes. But sometimes a worker in the field needs more than just a welder. The Cross Country 300 gives you plenty of single and three phase AC generator power for grinders, pumps and trailers. It all comes in a compact, lightweight package that will fit into any truck bed and give you plenty of visibility through the rear window.

Specifications

Arrester : Optional
Auxiliary Output Type Phase : 1
Auxiliary Output Voltage : 10,000 watt
Brand : Lincoln Electric
Case Type : Painted
Category : Engine Drive Welding Systems
Connector Type : No
Control Type : Continuous
Controller : Mechanical
Coolant Capacity : 1.2 gal
Cooling System : Water
Country of Origin : USA
Emissions Rating : US EPA Tier 4 Final
Engine Block Size : 1.5 Liter
Engine Brand : Kubota
Engine Cylinders : 4
Engine Protections : High Temperature
Engine Specifications : 4
Engine Starting : Manual
Engine Type : Naturally Aspirated
EPA Certified : Yes
Equipment : Generator
Fuel Consumption : .4 gal/hour
Fuel Tank Capacity : 11.6 gal
Fuel Type : Diesel
Height : 31.9 in
Horsepower : 16.4 kw
IEC Rating : 300 Amp
Ingress Protection Rating : IP23
Input Icon : D
Input Style : Engine
Input Voltage : Engine
Jumper Terminals : Yes
Length : 56 in
Low Idle Operating Speed : 1,350
Machining Process : Flux-Cored Gas-Shielded
Maximum Output : 300-399
Maximum Rating : 350 Amp
Motor Type : Naturally Aspirated
Number of Control Knobs : 2
Oil Capacity : 6 Liter
Open Circuit Voltage : 80
Operating Speed : 1,800
Output : CC/CV
Output Current : DC
Output Frequency : 60 Hz
Output Meters : Digital
Output Mode : CC
Polarity : DC
Rated Gouging Carbon Diameter : 1/4 in
Receptacle Type : NEMA 14-50R
Remote Control Type : Wired
Temperature Rating : 40 deg C
Three Phase Auxiliary Output : 11,000 watt
User Interface Type : Knob
VRD : Option
Warranty : 3 Year
Warranty Length : 3 yrs
Weight : 1034 lbs
Welding Controls : Chopper
Welding Mode : CC-Stick
Welding Thechnology : Chopper
Width : 25.3 in
Work Clamp Included : No
