Maverick® 325X (Kubota®)

Locations: In Stock Call for Availability

Item Code: LNCK3581-1

Category Engine Drive Welding Systems

Description

The Maverick® 325X is an advanced engine-driven welder with the perfect combination of size, performance, and innovation. This best-in-class arc welding machine provides substantial power and promotes fuel savings with variable engine RPM and auto start/stop capabilities. In addition, the machine boasts an advanced user interface on a heavy-duty 4.6 in. weatherproof LCD screen. The machine also features CrossLinc® technology, which allows the adjustment of machine output at the arc to promote productivity, site safety, and overall weld quality.

Specifications

Amperage : 325 Amp
Arrester : Optional
Auxiliary Output Voltage : 10,000 watt
Brand : Lincoln Electric
Category : Engine Drive Welding Systems
Controller : ECU
Coolant Capacity : 0.9 liter
Cooling : Water
Country of Origin : Canada
CrossLinc : Enabled
Display Size : 4.6 in
Emission : US EPA Tier 4 Final
Engine Block Size : 0.9 liter
Engine Brand : Kubota
Engine Starting : Auto-Stop/Start
Engine Type : Naturally Aspirated
Fuel Consumption : 1.21 gal/hour
Fuel Tank Capacity : 11.5 liter
Fuel Type : Diesel
Height : 34.23 in
Horsepower : 18.5 kW
Ingress Protection : IP23
Input Voltage : Engine
Length : 1379 mm
Low Idle Operating Speed : 2500 rpm
Maximum : 400 Amp
Number of Engine Cylinders : 3
Oil Capacity : 3.7 liter
Open Circuit Voltage : 80
Operating Speed : 3600 rpm
Polarity : DC
Prop 65 Compliant : Prop 65 Compliant
Rated Gouging Carbon Diameter : 5/16 in
Remote Control Type : CrossLinc
User Interface Type : Display Screen
Voltage : 120 Volt
VRD : Yes
Weight : 340.2 kg
Welding Controls : Chopper
Welding Mode : Arc Gouging
Welding Technology : Chopper
Width : 21.25 in

Maverick® 325X (Kubota®)

Locations: In Stock Call for Availability

Item Code: LNCK3581-1

Category Engine Drive Welding Systems

Description

Specifications

Amperage : 325 Amp
Arrester : Optional
Auxiliary Output Voltage : 10,000 watt
Brand : Lincoln Electric
Category : Engine Drive Welding Systems
Controller : ECU
Coolant Capacity : 0.9 liter
Cooling : Water
Country of Origin : Canada
CrossLinc : Enabled
Display Size : 4.6 in
Emission : US EPA Tier 4 Final
Engine Block Size : 0.9 liter
Engine Brand : Kubota
Engine Starting : Auto-Stop/Start
Engine Type : Naturally Aspirated
Fuel Consumption : 1.21 gal/hour
Fuel Tank Capacity : 11.5 liter
Fuel Type : Diesel
Height : 34.23 in
Horsepower : 18.5 kW
Ingress Protection : IP23
Input Voltage : Engine
Length : 1379 mm
Low Idle Operating Speed : 2500 rpm
Maximum : 400 Amp
Number of Engine Cylinders : 3
Oil Capacity : 3.7 liter
Open Circuit Voltage : 80
Operating Speed : 3600 rpm
Polarity : DC
Prop 65 Compliant : Prop 65 Compliant
Rated Gouging Carbon Diameter : 5/16 in
Remote Control Type : CrossLinc
User Interface Type : Display Screen
Voltage : 120 Volt
VRD : Yes
Weight : 340.2 kg
Welding Controls : Chopper
Welding Mode : Arc Gouging
Welding Technology : Chopper
Width : 21.25 in

Starting from

$19,883.44
